Features

• Simply drag/drop symbols to produce 19" rack layouts in seconds.
• High detail front and rear views.
• Side view showing recommended clearance for connectors etc.
• Document grid of 1" across and 1RU high for ease of positioning and spacing of products to allow for ventilation etc.
• Symbols at 1:1 scale - show dimensions directly on drawing.

New in 7.4

• High DPI Support: pin-sharp, eye-popping detail on high-res monitors, 4K, 5K, 8K and beyond.
• Clone Drawing: create new Rack Layouts based on an existing drawing but with new product instances to create similar but distinct systems.

Symbols

Detailed, 1:1 scale, line art symbols of front, rear and side (depth only) views of products.

Layers

Default layers for front high and low detail, rear high and low detail, side view and side view clearances.
